Architrave keypads, Austin, Texas

Lutron Architrave Narrow Keypads in Austin

Slim, low-profile HomeWorks keypads with 5 or 7 engraved buttons, designed and installed by Smarter Homes.

Great room with wood ceiling, pendants, and floor-to-ceiling glass
Lutron application photo: great roomImage: Lutron Electronics Co., Inc.
What it is

Lutron's slimmest keypad

Architrave is a narrow, low-profile HomeWorks keypad that sits nearly flush with the wall and takes up almost no visual space (Lutron Architrave). Lutron positions it for minimalist interiors and for renovations where controls need to stay nearly invisible. Raised buttons give tactile landmarks, and green LEDs beside the buttons confirm the active scene.

Architrave 5-button keypad in painted white with scene labels Entertain, Casual, Relax, Bright, Off
Architrave in Painted White with engraved scene labelsImage: Lutron Electronics Co., Inc.

5 or 7 buttons

The 5-button version includes raise and lower buttons for shades or dimming. The 7-button version is for more scenes.

Door Wide or Door Narrow

Lutron's spec sheet lists both widths for each button count.

Engraved faceplates

Custom text or icons identify each button. Faceplates are field-changeable.

Status LEDs

Green LEDs show which scene is active. Raise and lower buttons have none.

Finishes

Architrave finishes: one matte and twelve metals

Every finish below shows an Architrave keypad in that finish, with its model color code from the Lutron Architrave spec sheet. Lutron recommends black buttons when you order a metal faceplate. The tag under each finish shows which other Lutron lines list the same finish name. See the real faceplates in the showroom (book a visit).

Image: Smarter Homes rendering based on Lutron product photography. Actual finish varies with lighting; see samples in the showroom.

Architectural matte (1)

Architrave keypad in White, rendered by Smarter Homes
WhiteCode WHalso: Palladiom, Signature, GRAFIK Eye QS

Brass and gold (5)

Architrave keypad in Satin Brass, rendered by Smarter Homes
Satin BrassCode SBalso: Palladiom, Signature, GRAFIK Eye QS
Architrave keypad in Antique Brass, rendered by Smarter Homes
Antique BrassCode QBalso: Palladiom, Signature, GRAFIK Eye QS
Architrave keypad in Bright Brass, rendered by Smarter Homes
Bright BrassCode BBalso: Palladiom, Signature, GRAFIK Eye QS
Architrave keypad in Brass Anodized Aluminum, rendered by Smarter Homes
Brass Anodized AluminumCode BRAalso: Signature, GRAFIK Eye QS
Architrave keypad in Gold, rendered by Smarter Homes
GoldCode AUalso: Signature

Nickel and chrome (4)

Architrave keypad in Satin Nickel, rendered by Smarter Homes
Satin NickelCode SNalso: Alisse, Palladiom, Aviena, Signature, GRAFIK Eye QS
Architrave keypad in Bright Nickel, rendered by Smarter Homes
Bright NickelCode BNalso: Palladiom, Signature, GRAFIK Eye QS
Architrave keypad in Bright Chrome, rendered by Smarter Homes
Bright ChromeCode BCalso: Alisse, Palladiom, Aviena, Signature, GRAFIK Eye QS
Architrave keypad in Satin Chrome, rendered by Smarter Homes
Satin ChromeCode SCalso: Palladiom, Signature, GRAFIK Eye QS

Bronze and aluminum (3)

Architrave keypad in Antique Bronze, rendered by Smarter Homes
Antique BronzeCode QZalso: Signature, GRAFIK Eye QS
Architrave keypad in Clear Anodized Aluminum, rendered by Smarter Homes
Clear Anodized AluminumCode CLAalso: Signature, GRAFIK Eye QS
Architrave keypad in Black Anodized Aluminum, rendered by Smarter Homes
Black Anodized AluminumCode BLAalso: Signature, GRAFIK Eye QS

Finish renders by Smarter Homes, based on Lutron product photography (Image: Lutron Electronics Co., Inc.). Overlap is by identical finish name across Lutron specifications; confirm with a chip before matching. Architrave is the only one of these lines that lists Gold (AU) and Signature lists it too. Actual finish varies with lighting; see samples in the showroom.

Where it fits

Controls that disappear into the architecture

Use Architrave where a standard keypad would be too wide, such as beside a door, on a narrow wall, or on a casing or trim run. Lutron describes it as an architectural element rather than an applied device. Its spec sheet also lists two contact-closure inputs on the back, for functions that do not use the front buttons.

Open dining and living room with a high ceiling and large windows
Lutron application photo: open living spaceImage: Lutron Electronics Co., Inc.
Specifications

Size, wiring, and boxes

ItemLutron says
SizeAbout 4.4 in tall, 1.25 in wide, 2.75 in deep
Back boxCustom Architrave wallbox (part 241399), sold separately; 2.75 in depth
WiringLow-voltage QS link; 24 to 36 V, 30 mA; 1 Power Draw Unit
Wire lengthUp to 2,000 ft on a HomeWorks QS wired link
Device limitUp to 100 devices on a HomeWorks QS wired link
SystemHomeWorks
Rating and warrantyIndoor use only, IP20; 8-year warranty

Lutron lists slightly different dimensions on its product page and its spec sheet, so we confirm the exact box and plate size for each job before rough-in.

Pricing

Get your price for your project

We price Architrave keypads to your finishes, counts and engraving. Book a showroom visit or call 512-775-6101 and we will put your list together.

Choosing

Architrave, Alisse, Palladiom, or Sunnata

Architrave is the narrowest option. Pick Alisse or Palladiom for a larger face and richer materials, Sunnata for a clean retrofit keypad, Aviena for brass toggles, and Signature for backlit buttons in a narrow body. Lutron lists Architrave with HomeWorks, and does not list RadioRA 3. See HomeWorks QSX.

Need to dim several lights and run shades from one spot? See the GRAFIK Eye QS. Bring your door and wall details to the showroom and we will show you how Architrave compares with the keypads on display.

Questions

Architrave FAQ

What is the Lutron Architrave keypad?

A narrow, low-profile wired HomeWorks keypad with 5 or 7 buttons, engraved faceplates, and green status LEDs. Lutron calls it its slimmest form factor.

Does Architrave work with RadioRA 3?

Lutron lists Architrave with HomeWorks. It does not list RadioRA 3.

How many buttons does it have?

Five buttons with raise and lower, or seven buttons. Each comes in Door Wide and Door Narrow configurations.

What finishes are available?

Architectural Matte White and twelve metal faceplate finishes, including brass, nickel, chrome, bronze, and anodized aluminum.

Can the buttons be engraved?

Yes. Faceplates can be engraved with custom text or icons and are field-changeable.

Does it need a special box?

Yes. Lutron lists a custom Architrave wallbox, sold separately.

How long is the warranty?

Lutron lists an 8-year warranty against defects in materials and workmanship.
